Drum Pulper aotian paper machinery-Aotian Machinery Manufacturing Co., Ltd.

Drum Pulper

Name: Drum Pulper

Model: AT275-AT425

Drum Diameter: ∅2750-∅4250

Capacity (T/D): 140-1400

A type Motor Power: 160-1000

B type Motor Power: 200-1250

Chat Now Inquire Now

Description

Drum pulper belongs to Pulping System of paper machinery and is a more advanced Pulping System. Drum pulper is a product which incorporates pulping and screening function and is particularly suitable for pulping the unsorted waste paper raw materials. For expanding the recovery and utilization the secondary fiber, reducing the environmental pollution, saving the energy, reaching the localization of papermaking equipment and saving the foreign exchange, the product has a greater economic and social benefits. Drum pulper is used for disintegrating continuously and coarse screening under a high concentration of waste paper raw materials (14%-22%).

Technical Data

Product name	Drum Pulper
Model	AT275	AT300	AT325	AT350	AT375	AT400	AT425
Drum Diameter	∅2750	∅3000	∅3250	∅3500	∅3750	∅4000	∅4250
Capacity (T/D)	140-200	200-300	300-400	400-550	550-720	750-1000	1000-1400
A type Motor Power	160	250	315	500	630	800	1000
B type Motor Power	200	315	400	630	800	1000	1250
