Paper board machine

Name: Paper board making machine

Model: 1092-5600

GSM: 90-300g/㎡

Production: Customization

Working speed: Customization

Center distance: According to models

Transmission form: Use AC frequency conversion and driving by step

Chat Now Inquire Now

Description

Main models：1092、1575、1760、1880、2100、2400、3800、4000、4200、4600、4800、5000、5200、5600etc.

The paper board making machine is classified according to the structure and type of the shaper and dryer. There are single long wire paper board machine, long wire paper board machine, long round wire mixed paperboard machine, and multiple round wire cardboard box making machine. The latter is the most widely used.

Technical Data

Paper grade	Paper board making machine
Net Paper width	1092-5600mm
GSM	90-300g/m2
Production	Customization
Working speed	Customization
Center distance	According to models
Transmission form	Use AC frequency conversion and driving by step
